FloorThane Electroshield ULD 5411

FloorThane Electroshield ULD 5411: Polyurethane based three-component, self leveling, Electrostatic Dissipation (ESD) Floor Coating

FloorThane Electroshield ULD 5411

Overview

FloorThane Electroshield ULD 5411, based on polyurethane resin, is a three-component, self-leveling floor coating formulated for electrostatic dissipation. It is a very low-odor, chemical-resistant, aliphatic polyester ESD urethane coating designed to provide effective electrostatic control. Electroshield ULD 5411 offers a non-yellowing, thin-film finish with a semi-gloss to satin appearance and is available in a range of colors and textures.

For More Info call us: +91-9323890195 Contact
  • Advantage
  • Specification Clause
  • Technical Data
  • Project Profile
  • Download

Advantage

  • Extremely low, non-offensive odor
  • Wide range of colors, including near-white and bright blues
  • Can be used as a clear ESD topcoat on flake and quartz floors
  • BVG below 15 volts with conductive footwear
  • Dissipates 5000 volts to 0 in under 0.1 seconds
  • Consistent conductivity without a ground plane primer
  • Maintains ESD performance regardless of humidity

Specification Clause

  • Abrasion Resistance (Tabor CS-17, mg loss/1000 cycles/1000g mass): ASTM D4060, 25 mg
  • Coefficient of Friction (COF): ASTM D2047, 0.55, with Gloss Grip 0.65
  • Elongation: ASTM D2370, 8%
  • Impact Resistance: ASTM D2794, 140 in.lbs Direct & Reverse
  • Hardness (Pencil): ASTM D3363, 2H

Technical Data

    • Flash Point (ASTM D3278): 80°C
    • Volume Solids (Mixed) (ASTM D2369): >74%
    • Mixed Viscosity (ASTM D2196): 300-500 cPs
    • Dry Time (ASTM D5895):

    Tack Free: 8 hrs

    Dry: 16-24 hrs

    Full Cure: 7-14 days



    • VOC (ASTM D3960): < 250 g/l (Pigmented)

Project Profile

Project profile coming soon!

Download

To access TDS, click here
